Mic Input | . |
Impedance/Gain | 2kW Balanced/65dB, 1kW Unbalanced/65dB |
Line Input | . |
Impedance/Gain | 20kW Balanced/45dB, 10kW Unbalanced/45dB |
THD | < 0.1 % |
Frequency Response | 25Hz-20 kHz (-1dB) |
Equalisation | . |
Bass/Treble | ±15dB at 80 Hz / ±15dB at 12kHz |
Digital Recorder | MP3 Recorder & Playback |
Delay Range | Variable from 20 to 300ms |
Line Output L/R | . |
Nominal | 0dBu (775mv) |
Maximum | +21dBu (9V) |
Output Impedance | 600W |
Headphone Output | 200mV at 8W |
S/N Ratio | > 68dB |
Clip LED Indication | 4dB prior to true clip |
Power Supply | 220-240V AC 50Hz |
Protection | AC: Fuse 1Amp. 250V (T 1A L) |
Dimensions | W345 x H75 x D210mm |
Weight | 1.85kg approx. |


Ahuja FMX-108DP 8 Channel Mixer With built-in MP3 Player & Audio Interface
₹7,210.00
Ahuja FMX 108DP is a professional grade 8 channel mixer that’s perfect for live performances! With its lightweight and compact design, this mixer is perfect for anyone who needs a reliable PA mixer that’s aesthetically pleasing and easily portable. This mixer is a great choice for any musician who needs a high-quality product on the go.
- Compact and reliable professional PA Mixer which is aesthetically superior and easily portable.
- Provided with two balanced XLR microphone inputs, with switchable +48V Phantom supply.
- Additionally, four low impedance microphones can be connected in either balanced or unbalanced configuration, through a 6.3 mm (1/4″) stereo jack socket.
- Upto six line level signal sources can be connected in either balanced or unbalanced configuration, through a 6.3mm (1/4″) stereo jack socket.
- Each channel has a GAIN control for optimum adjustment of the MIC & LINE input sensitivities.
- Two band equalizer with active BASS & TREBLE controls in each channel for desired equalisation of the input signal.
- Separate FX (effects) level control for each input channel.
- MP3 digital player with recording and playback through USB. Bluetooth facility also available.
- One independent stereo input channel is provided with a GAIN control, 2 band EQ, FX & LEVEL Controls.
- Each channel has a PEAK LED which glows when the level of input signal is excessive.
- A push switch is provided for selection between Ch 7/8 and USB channel.
- Built-in digital effects processor with DELAY, REPEAT and LEVEL controls.
- Effects ON/OFF switch with FX ON & PEAK LEDs.
- Line level LEFT & RIGHT outputs through 6.3 mm (1/4″) stereo jack sockets.
- Headphone output, with independent volume control, is available through a 6.3mm (1/4″) stereo jack socket.
- Individual SIGNAL & CLIP LEDs for optimum setting of Left & Right output levels.
- Individual MASTER volume controls for Left & Right line outputs.
- Operates on 240V, 50Hz AC Mains.
In stock
Additional information
Brand | AHUJA |
---|---|
CHANNELS | 8 channels |
CATEGORIES | Medium & Large Mixers |
FEATURES | Bluetooth, Inbuilt Recording, USB option |
