Studiomaster AQUA 10 Mixer (10 Channel)

22,190.00

  • 8 Mic/Line + 2 Stereo
  • 3 Band EQ per Channel.
  • Mic / Line selectivity switch on each mono channel with 20 dB PAD for mic input.
  • Mix, Group & PFL Routing per channel.
  • L/R Pan control & signal LED per channel.
  • 2 Aux Sends – Aux + EFX (When internal FX is not used).
  • Globally Switched +48V Phantom Power.
  • Headphone and monitor outputs with level control
  • 2 Sub groups with Individual outputs.
  • 7 band stereo Graphic Equalizer.
  • Built in 24-bit Multi-FX processor with Tap Tempo.
  • Stereo RCA Playback & record outputs.
  • FS mute jack to connect to a standard footswitch to switch On/Off internal EFX.
  • Balanced XLR Outputs.

In stock

Studiomaster AQUA 10 | Phantom power mixer | 10 channel mixer
Studiomaster AQUA 10 Mixer (10 Channel)
22,190.00
Model AQUA 10

Nominal Gain (Mic/Line/Stereo Line) 60dB/40dB/20dB

Max Gain ( Mic/Line/Sterio Line) 80dB/60dB/40dB

Input sensitivity
Mic (Gain Min/Gain Max) -10dBu/ -60dBu

Line (Gain Min /Gain Max) +10dBu / -40dBu

Stereo Line (Gain Min /Gain Max) +10dBu / -20dBu

Input Impedance
Mic Input 2KΩ Balanced

Line Input 20KΩ (Balanced) / 10KΩ (Unbalanced)

Main Output Level (Nominal / Max) 0dBu (0.775V RMS) / +22dBu (10V RMS)

Main Output Impedance 75Ω

Frequency Response 20Hz to 20KHz (+0/-2 dB)

Total Harmonic Distortion < 0.006%

Signal to Noise Ratio 85dB

Equalisation
Mono MIC          (Treble/Mid/Bass) ±15dB (12KHz HF / 2.5 KHz MF/60Hz LF)

Stereo Line        (Treble/Mid/Bass) ±15dB (12KHz HF / 2.5 KHz MF/80Hz LF)

Effects 16 Effects, 24-Bit EFX Processor

Phantom Supply +48V

Dimensions (W x D x H in mm) 430 x 317x 134

Net Weight (Kgs.) 5.5

Additional information

Brand

STUDIOMASTER

CATEGORIES

Medium & Large Mixers

CHANNELS

10 channels
