| Model | Orb 1822 |
| Nominal Gain (Mic / Line / Stereo Line) | 60dB / 40dB / 20dB |
| Max Gain (Mic/Line/Stereo Line) | 80dB / 60dB / 40dB |
| Input Output Levels | |
| Mic (Gain Min/Gain Max) | -10dBu / -60dBu |
| Line (Gain Min /Gain Max) | +10dBu / -40dBu |
| Stereo Line (Gain Min /Gain Max) | +10dBu / -20dBu |
| Aux Return (Nominal / Max) | -10dBu / +30dBu |
| Clip indication | 5dB prior to true clip |
| Main Output, Group Output, Aux Send, Record Out (Nominal / Max) | 0dBu (0.775V RMS) / +20dBu (7.75V RMS) Max |
| Insert In/Out (Nominal / Max) | 0dBu (0.775V RMS) / +20dBu (7.75V RMS) Max |
| Mic Input Impedance | 5KΩ Balanced |
| Line Input Impedance | 20KΩ Balanced / 10KΩ Unbalanced |
| Frequency Response | 20Hz-20kHz (+0 / -1dB) |
| Total Harmonic Distortion | < 0.02% |
| Cross-talk | -80dB |
| MIC EIN (Equivalent Input Noise) | -128dB |
| Main Out/Group Out | -80dB |
| Aux Send | -70dB |
| Record Out | -77dB |
| Equalization | |
| Mono MIC (Hi / Hi-Mid / Low-Mid / Low) | ±15dB @ 12kHz / 2.5kHz / 400Hz / 80Hz |
| Stereo Line (Hi / Hi-Mid / Low-Mid / Low) | ±15dB @ 12kHz / 2.5kHz / 400Hz / 80Hz |
| 7-Band Stereo Equalizer | ±12dB @ 15kHz / 6.4kHz / 2.5kHz / 1kHz / 400Hz / 150Hz / 63Hz |
| Low Cut | -3dB @ 75Hz |
| Miscellaneous | |
| Effects | 24-bit/48kHz Sampling Rate 2 x 24 DSP Presets |
| Phantom Supply | +48V |
| Power Supply | 150V-240V / 50Hz |
| Fuse | 2A 250V AC |
| Power Consumption | 22W Max |
| Dimensions (W x D x H) mm | 820 x 490 x 160 |
| Net Weight (Kg) | 13 |
Studiomaster ORB 1822 Mixer with Bluetooth and Recording
₹40,900.00
Availability: In Stock
• Professional audio mixing consoles with 18 mic / 20 line inputs.
• MON:Ster (mono-stereo) inputs for full flexibility.
• One Knob Compressor on channels 1-8.
• Ultra low-noise preamps with wide headroom and dynamic range.
• Dual multi-EFX processor with 24 DSP presets and editable parameters.
• Provisions to route EFX to monitor via Aux 1 and Aux 2.
• Built-in USB MP3 media player and recorder with Bluetooth.
• Level control, 2-band EQ with internal/external media input selection.
• 75Hz low cut on mono channels.
• 4-band EQ on all inputs.
• 5 Aux sends – Aux 1-3 (with pre/post selection) and Aux 4-5 (post only).
• Stereo AUX returns.
• Balanced XLR and ¼” jack main outputs.
• 2 sub groups with individual ¼” outputs.
• Insert (send/return) on first 4 mono channels and main output.
• Mute, solo, group (G1-G2) and main (L-R) routing per channel.
• Peak, comp, mute and solo LEDs per channel.
• Stereo RCA input and record output.
• Headphone output with level control.
• Globally switched +48V Phantom power supply.
• Responsive 60mm faders.
• 7-band stereo graphic equalizer on main output.
• Dual 10-segment LED meter for main, group and solo outputs.
• Ergonomic angled-design for better visibility.
• Clutter-free rear panel input and output connectivity.
Only 1 left in stock
| Brand | STUDIOMASTER |
|---|---|
| CATEGORIES | Premium Mixers |
| CHANNELS | 18 channels |
| FEATURES | Bluetooth, Inbuilt Recording, USB option |
