Power Output | |
4 Ω (True RMS),20Hz-20kHz,1% THD | 2 x 1900 W |
4 Ω (EIA), 1kHz , 1%THD | 2 x 2500 W |
8 Ω (True RMS),20Hz-20kHz,1% THD | 2 x 1200 W |
8 Ω (EIA), 1kHz , 1%THD | 2 x 1400 W |
Bridged Mode | |
8 Ω (True RMS), 20Hz-20kHz, 1% THD | 3800 W |
8 Ω (EIA), 1kHz , 1%THD_ | 5000 W |
Damping factor | > 350 :1 (8 Ω) |
Frequency Response | 20Hz – 20kHz (-3dB) |
Protection Devices | Temperature, DC, Short Circuit, Soft Start |
Input Connector (Per Channel) | XLR, 1/4” TRS Jack |
Output Connector (Per Channel) | Speakon / Binding Posts |
Dimensions (W x D x H)mm | 482 x 530 x 132 (3U) |
Net Weight (Kgs.) | 32 |


Studiomaster DJA 5000 Dual Channel Amplifier (2500+2500 watts)
₹59,700.00
- Rugged & Reliable Professional Stereo Power Amplifier.
- Input: Balanced XLR & 1/4” Jack.
- EQ Processing, Low Cut, Subwoofer selection options on rear panel.
- Stereo, Bridge & Parallel mode selection switch.
- Protection: Temperature, DC Short Circuit.
- Large cooling Fans.
- LED Indicators on front panel for power, Signal, Clip, bass boost & Protect.
- Mains voltage operation 220V AC-240V AC as well as low voltage operation (150V AC).
- Output: Speakon & Binding Post Connectors.
- 19” rack mountable.
- Works on 2 Ohms.
Out of stock
Additional information
Brand | STUDIOMASTER |
---|---|
MODEL | Dual Zone |
WATTAGE | 2501-7500 |
